Loading... Please wait...| TECHNICAL SPECIFICATION RM80 | ||||
| Chasis 1250 mm | Chasis 1400 mm | Chasis 1450 mm | ||
| Motor Type | RM80 | |||
| Cylinder | 78 cc (47,7x44mm) | |||
| Carburettor | Walbro 24 mm. | |||
| Power & Ignition | 16 CV / 9400 R.P.M. Electronic | |||
| Reduction gear | Mechanical in oil bath, inclined teeth | |||
| Reduction ratio | 1/3,65 | |||
| Transmission | Centrifugal clutch | |||
| Start | Manual | |||
| *Thrust (kg) | aprox. 49kg | aprox. 54kg | aprox. 56kg | |
| Fuel | Leaded or unleaded Super grade + synthetic oil 2% | |||
| Fuel Circuit | PRIMER | |||
| Fuel Tank | 13,5 L | |||
| *Autonomy hours | aprox. 3.30 h. | |||
| Cage | Stainless Steel / T.I.G. | |||
| Paramotor weight | 25 kg. | 26 kg. | 26,5 kg. | |
| Haess size: S, M, L, XL | Sup´Air Special PAP | |||
| Propeller Size | 115 cm. | 125 cm. | 130 cm. | |
| Paramotor Size | 125 x 125 x 43 | 140 x 140 x 43 | 145 x 145 x 43 | |
| Max. Pilot weight | 80 kg. | 90 kg. | 95 kg. | |
| Recommended Pilot weight | 65 kg. | 75 kg. | 75 kg. | |
| OPTIONS RM80 | ||
| Cage 1200 mm.(Light) Size | NO | |
| Cage 1250 mm. Size | OPTIONAL | |
| Cage 1400 mm. Size | OPTIONAL | |
| Cage 1450 mm. Size | OPTIONAL | |
| Cage Division (2 PARTS) | OPTIONAL | |
| Cage Division (3 PARTS) | OPTIONAL | |
| Cage Division (5 PARTS) | OPTIONAL (ONLY for 1400RM) | |
| Wood propeller | STANDARD (NO for 1450RM) | |
| Carbon fibre propeller | OPTIONAL (STANDARD for 1450RM) | |
| Propeller Covers | STANDARD | |
| Mousqueton Parafly Acier | OPTIONAL | |
| Zicral Autolock Carabine | STANDARD | |
| Haess Wood Board | STANDARD | |
| Haess Carbon Board | OPTIONAL | |
| ACCESSOIRES RM80 | ||
| H.R.S. Container | OPTIONAL | |
| S.R.S. Lateral Container | OPTIONAL | |
| RPM Counter | OPTIONAL | |
| Fuel Hose Coupling | OPTIONAL | |
| Cage Luggage Bag | OPTIONAL | |
| Engine Luggage Bag | OPTIONAL (NO 2 PARTS CAGE) | |
| ATS System | OPTIONAL | |
